CNYST

CNYST Disintegration Test Apparatus Disintegration Test Machine with Double Cups and Two Channels High Temperature Control Accuracy Basket Round-Trip Frequency (30～32) Times/min Timing Range (1 to 900) Minutes Timing Accuracy ±0.5min

$1,233.00

About this item:

Double cups and two channels, each channel runs independently and can be controlled separately; automatic timing shutdown.

Automatic temperature control, high temperature control accuracy.

Using a micro water pump circulating water flow uniform heating system, the temperature of the water bath is uniform.

Automatic and intelligent control of three parameters: temperature, time and round-trip frequency.

You can preset time parameters at will; display preset value and real-time value in time division.

Application:

Disintegration time limit tester is used to check the disintegration of solid preparations under specified conditions.

Features:

Two cups, twelve tubes.

Double cups and two channels, each channel runs independently and can be controlled separately; automatic timing shutdown.

Automatic temperature control, high temperature control accuracy.

The hanging blue and the hanging rod are made of imported stainless steel.

Using a micro water pump circulating water flow uniform heating system, the temperature of the water bath is uniform.

Automatic and intelligent control of three parameters: temperature, time and round-trip frequency.

You can preset time parameters at will; display preset value and real-time value in time division.

Automation, automatic detection, automatic diagnosis, automatic alarm.

Technical indicators:

Basket assembly:2

Number of hanging glass tubes:12

Flat bottom beaker volume:1000ml

Basket round-trip frequency:(30～32) times/min

Basket round trip:(55±1)mm

Minimum spacing of screen mesh:(25±2)mm

Timing range:(1 to 900) minutes

Timing accuracy:±0.5min

Temperature preset range:(20～45)℃

Automatic temperature control accuracy:±0.5℃

Heater power:500W

Continuous working time:more than 24 hours

Power supply :220V/ 50Hz/ 600W or 110V/ 60Hz/ 600W

Power:600W

Overall dimensions:(40×30×42)cm3

Weight :18kg
